Productus

Hex Cap fines

Standard: CMXII
Thread Type: Crassum filum, partialis filum
Commodity: Hex Cappella
Etiam nominatur: Din CMXII Allen fulmine
Material: Carbon Steel
Property Class: 8.8,10.9,12.9
Diameter: M1.4/ M1.6/ M2/ M2.5/ M3/ M4/ M5/ M6/ M8/ M10/ M12/ (M14)/ M16/ (M18)/ M20/ (M22)/ M24/ (M27)/ M30/ (M33)/ M36/ M42/ M48/ M56/ M64/ M72/ M80/ M90/ M100
Consummare, patet, nigrum cadmiae, cadmiae patella, calidum aspersa galvanized, oxidatio, Dacromet, phosphaating, Cadmium electropligitur, Nickel patella
Caput Type: Caput
Type Coegi: Hexagon Capket
Alternative vexillum: GB / T 70.1, ISO (IV) DCCLXII, LINT en ISO (XII) CDLXXIV, ANSI / ASME B 18.3.1M, UNI (V) CMXXXI, NF E 25-125, ut MCDXX
MOQ: 1000kgs
Duc Tempus: XXX ad LX diebus

mitte Inquisitionis

Product Online

Aya fasteners (Hebei) Co., Ltd est unus ex maxime periti Manufacturers et Suppliosers Hex Cappella Cap folia in Sinis. Placere sentire liberum emere altus qualitas hexensi capillus Cap folia in Sina hic de officina. Nam pretium consultatio, contact us.

Hex Socket Cap Bolts-AYA

Ut a global elit de customized pavere solutions, Aya scriptor Service processum est etiam ut proxima ad customers ut Aya scriptor products. Ex describendo necessitates sequantur, {{I}} Sursum Services, Aya et prompte et parce non conatu ad auxilium customers solvere aliquo assentientibus problems, quae surge, ut eliminate de customers.

Product Description

Product Name	Hex Cap fines
Et nominatur	Laudate CMXII Allen fulmine
Materia	Carbon Steel
Vexillum	Laudate CMXII
ALIGNIS	GB / T 7,1, ISO (IV) DCCLXII, LING EN ISO (XII) CDLXXIV, ANSI / ASME b 18.3.1M, UNI (V) CMXXXI, NF E 25-125, ut MCDXX
Proprietas	8.8,10.9,12.9
Diameter	M1.4/ M1.6/ M2/ M2.5/ M3/ M4/ M5/ M6/ M8/ M10/ M12/ (M14)/ M16/ (M18)/ M20/ (M22)/ M24/ (M27)/ M30/ (M33)/ M36/ M42/ M48/ M56/ M64/ M72/ M80/ M90/ M100
Consumo	Patet, nigrum cadmiae, cadmiae patella, calidum intinxit galvanized, oxidatio, Dacromet, phosphaating, Cadmium electroplate, nickel patella
Caput type	Pentium Caput
TRIGUOR	Hexagon Service
Filum genus	Cooks filum, partialis filum

Dimensiones mensam

Hex Socket Cap Bolts-2D

Screw filum d			M1.4	M1.6	M2	M2.5	M3	M4	M5	M6	M8	M10
Screw filum d			M1.4	M1.6	M2	M2.5	M3	M4	M5	M6	M8	M10
P	Pice	Crassum filum	0.3	0.35	0.4	0.45	0.5	0.7	0.8	1	1.25	1.5
		Fine filum pice-I	-	-	-	-	-	-	-	-	1	1.25
		Fine filo pice-II	-	-	-	-	-	-	-	-	-	1
dk	caput	max	2.6	3	3.8	4.5	5.5	7	8.5	10	13	16
	capitibus	max	2.74	3.14	3.98	4.68	5.68	7.22	8.72	10.22	13.27	16.27
	min		2.46	2.86	3.62	4.32	5.32	6.78	8.28	9.78	12.73	15.73
da	max		1.8	2	2.6	3.1	3.6	4.7	5.7	6.8	9.2	11.2
ds	max		1.4	1.6	2	2.5	3	4	5	6	8	10
ds	min		1.26	1.46	1.86	2.36	2.86	3.82	4.82	5.82	7.78	9.78
e	min		1.5	1.73	1.73	2.3	2.87	3.44	4.58	5.72	6.86	9.15
k	max		1.4	1.6	2	2.5	3	4	5	6	8	10
k	min		1.26	1.46	1.86	2.36	2.86	3.82	4.82	5.7	7.64	9.64
s	Nomini		1.3	1.5	1.5	2	2.5	3	4	5	6	8
	min		1.32	1.52	1.52	2.02	2.52	3.02	4.02	5.02	6.02	8.025
	max		1.36	1.56	1.56	2.06	2.58	3.08	4.095	5.14	6.14	8.175
t	min		0.6	0.7	1	1.1	1.3	2	2.5	3	4	5
w	min		0.5	0.55	0.55	0.85	1.15	1.4	1.9	2.3	3	4
Screw filum d			M12	(M14)	M16	(M18)	M20	(M22)	M24	(M27)	M30	(M33)
Screw filum d			M12	(M14)	M16	(M18)	M20	(M22)	M24	(M27)	M30	(M33)
P	Pice	Crassum filum	1.75	2	2	2.5	2.5	2.5	3	3	3.5	3.5
		Fine filum pice-I	1.25	1.5	1.5	1.5	1.5	1.5	2	2	2	2
		Fine filo pice-II	1.5	-	-	2	2	2	-	-	-	-
dk	caput	max	18	21	24	27	30	33	36	40	45	50
	capitibus	max	18.27	21.33	24.33	27.33	30.33	33.39	36.39	40.39	45.39	50.39
	min		17.73	20.67	23.67	26.67	29.67	32.61	35.61	39.61	44.61	49.61
da	max		13.7	15.7	17.7	20.2	22.4	24.4	26.4	30.4	33.4	36.4
ds	max		12	14	16	18	20	22	24	27	30	33
ds	min		11.73	13.73	15.73	17.73	19.67	21.67	23.67	26.67	29.67	32.61
e	min		11.43	13.72	16	16	19.44	19.44	21.73	21.73	25.15	27.43
k	max		12	14	16	18	20	22	24	27	30	33
k	min		11.57	13.57	15.57	17.57	19.48	21.48	23.48	26.48	29.48	32.38
s	Nomini		10	12	14	14	17	17	19	19	22	24
	min		10.025	12.032	14.032	14.032	17.05	17.05	19.065	19.065	22.065	24.065
	max		10.175	12.212	14.212	14.212	17.23	17.23	19.275	19.275	22.275	24.275
t	min		6	7	8	9	10	11	12	13.5	15.5	18
w	min		4.8	5.8	6.8	7.8	8.6	9.4	10.4	11.9	13.1	13.5
Screw filum d			M36	M42	M48	M56	M64	M72	M80	M90	M100	-
Screw filum d			M36	M42	M48	M56	M64	M72	M80	M90	M100	-
P	Pice	Crassum filum	4	4.5	5	5.5	6	6	6	6	6	-
		Fine filum pice-I	3	3	3	4	4	4	4	4	4	-
		Fine filo pice-II	-	-	-	-	-	-	-	-	-	-
dk	caput	max	54	63	72	84	96	108	120	135	150	-
	capitibus	max	54.46	63.46	72.46	84.54	96.54	108.54	120.54	135.63	150.63	-
	min		53.54	62.54	71.54	83.46	95.46	107.46	119.46	134.37	149.37	-
da	max		39.4	45.5	52.6	63	71	79	87	97	107	-
ds	max		36	42	48	56	64	72	80	90	100	-
ds	min		35.61	41.61	47.61	55.54	63.54	71.54	79.54	89.46	99.46	-
e	min		30.85	36.57	41.13	46.83	52.53	62.81	74.21	85.61	97.04	-
k	max		36	42	48	56	64	72	80	90	100	-
k	min		35.38	41.38	47.38	55.26	63.26	71.26	79.26	89.13	99.13	-
s	Nomini		27	32	36	41	46	55	65	75	85	-
	min		27.065	32.08	36.08	41.08	46.08	55.1	65.1	75.1	85.12	-
	max		27.275	32.33	36.33	41.33	46.33	55.4	65.4	75.4	85.47	-
t	min		19	24	28	34	38	43	48	54	60	-
w	min		15.3	16.3	17.5	19	22	25	27	32	34	-

Product Details

Hex Socket Cap Bolts-detail

Productum commoda

Hex Socket Cap Bolts-advantages

CommodaHex Cap fines

I. Caput figura de Allen cap Screw potest portare maius onus.

II. Quia caput necessitates ad embedded in partibus, nexu vires in HEX Cappella Cap serpere.

III. Comparari Ordinarius Bolts, Laudate CMXII Allen seras potest consequi altius torque et clamping vi.

IV. Sub conditione eiusdem clamping vis, paucioribus Hexagon Services Bolts sunt usus.

V. Paucioribus EXERCITATIO et percussoque in montem superficies, salvis et reducendo potential damnum ad components.

VI. Usus Allen fulmine crepitus CMXII potest reducere pondus consummavi uber.

VII. Aya providebit vobis cum maxime idoneam figuram solution secundum ipsam situ in area.

Qualis inspectionem

Hex Socket Cap Bolts-check

Expertus QC Staff potest providere customers cum accurate qualis inspectionem tradit.

Nostrum digital ratio servat se batch traceable a rudis materiae ad complevit products. Qualitas inspectionem testimoniales potest oblatum petitionem.

Packaging & continens loading

Hex Socket Cap Bolts-package

Packaging est momenti ad productum conservationem tum salutem. Aya est semper developed novus solutions ut products integrum per sit amet processus.

Usus missionibus

Hex Socket Cap Bolts-usage
